| Voltage | 380VAC/220VAC |
| Max Static Load | 1800KG |
| Suspection | 2:1 |
| Control Method | VVVF |
| Brake | DC110V, 2X1.9A |
| Weight | ERS: 160kg ERSC:140kg |
| Model | Load(kg) | Lift speed m/s | Height | Sheave Diam (mm) | Rope Sheave (mm) | Motor Power (KW) | IP Grade |
|---|---|---|---|---|---|---|---|
| ERSC | 320 | 1 | ≤80 | Φ240 | 4xΦ6.5x12 | 2.1 | IP41 |
| ERSC | 320 | 1.5 | ≤80 | Φ240 | 4xΦ6.5x12 | 3.1 | IP41 |
| ERSC | 320 | 1.6 | ≤80 | Φ240 | 4xΦ6.5x12 | 3.3 | IP41 |
| ERSC | 320 | 1.75 | ≤80 | Φ240 | 4xΦ6.5x12 | 3.7 | IP41 |
| ERS | 450 | 1 | ≤80 | Φ320 | 4xΦ8x12 | 3 | IP41 |
| ERS | 450 | 1.5 | ≤80 | Φ320 | 4xΦ8x12 | 4.5 | IP41 |
| ERS | 450 | 1.6 | ≤80 | Φ320 | 4xΦ8x12 | 4.8 | IP41 |
| ERS | 450 | 1.75 | ≤80 | Φ320 | 4xΦ8x12 | 5.3 | IP41 |
| ERS | 630 | 1 | ≤80 | Φ240 | 7xΦ6.5x12 | 4 | IP41 |
| ERS | 630 | 1.5 | ≤80 | Φ240 | 7xΦ6.5x12 | 6 | IP41 |
| ERS | 630 | 1.6 | ≤80 | Φ240 | 7xΦ6.5x12 | 6.4 | IP41 |
| ERS | 630 | 1.75 | ≤80 | Φ240 | 7xΦ6.5x12 | 7 | IP41 |
